☞ We have Q-switched laser heads, which can be used in laser rangefinders and target pointers, etc. Laser heads design ensures resistance to great temperature and thermal exposure which makes it possible to use the laser heads in field conditions.
BQH-1064HP, a high power Q-switched Nd:YAG Laser fetures water proof casing, compact design, high energy per pulse, high repetition rate range, built in energy meter, works reliable at field application.
Nd:YAG generator and amplifier provides for high energy of laser radiation. Special design of generator ensures stability of laser energy within wide range of pulse repetition rate.
Q-switch Laser Heads
BQH-1064S
| 파 장 | |
| 1064 | |
| Q-switching | |
| 100(Pumping energy less than 5J) | |
| 5 | |
| 3.5 | |
| Natual Air Cooling | |
| LiNbO3 | |
| -35-+55 | |
| up to 10G | |
| 50x60x180 |
BQH-1064
| Wavelength | |
| 1064 | |
| Q-switching | |
| 120(pumping energy less than 7J) | |
| 25 | |
| 4.5 | |
| Foced Water Cooling | |
| LiNbO3 | |
| -35-+55 | |
| 20G 이내 | |
| 50x50x180 |
BQH-1064M
| Wavelength | |
| 1064 | |
| Q-switching | |
| 140(pumping energy less than 7J) | |
| 25 | |
| 3.5 | |
| Foced Water Cooling | |
| LiNbO3 | |
| -35-+55 | |
| up to 10G | |
| 50x70x190 |
BQH-1064HP (방수외장)
| Wavelength | |
| 1064 | |
| up to 0.75 | |
| 8-10 | |
| 5-50 | |
| without beam spreader: 6 with 3x beam spreader: 2 |
|
| Foced Water Cooling | |
| -35-+55 | |
 |
|
| 120x205x420 |
BQH-1570
| Wavelength | |
| 1570(KTP OTO) *OPO technology is used to produce 1570nm laser radiation. |
|
| Q-switching | |
| 35(up to 50)(pumping energy less than 7J) | |
| 15(up to 25) | |
| 7 | |
| Foced Water Cooling | |
| LiNbO3 | |
| -35-+55 | |
| 10G 이내 | |
| 50x70x190 |
GE-100(Generator)*Amplifier, power supply, cooling unit and control unit are also available on request. *Set includes generator power supply, amplifier power supply, cooling unit and control unit.
| Specifications | |
| 1500 | |
| 1500 | |
| 3000 | |
| by PC, RS 232/RS 422 | |
| 220V, 50/60Hz | |
